Double-ring spanner, 16 x 17 mm, cranked


Item no.: 01212L
EAN: 4033592001687


variant: L SB
L: Loose and SB: SB-packing

Information about the product

Description

Manufactured according to DIN 838 / ISO 10104, ISO 3318, ISO 1085

  • With deep cranked ring heads
  • Ideal for tightening and loosening sunken bolts
  • The slim shape as well as narrow heads guarantee a minimal space requirement
  • With SW STAHL PRO DRIVE profile
    • Specially recessed shaft profile that prevents slipping or twisting of the screw
    • The enlarged contact surface ensures a secure torque transmission
    • The optimally distributed force transmission generates higher torques by up to 20%
    • Even screws outside the tolerances can be easily tightened and loosened
  • Galvanic coating for preventing corrosion
  • Made of high-quality chrome vanadium steel
  • Matt chrome-plated

Technical data

Spanner Off-set
Specification PRO DRIVE
Material Chrome Vanadium Steel
Spanner Size 16
Spanner Size 17
Quality Premium
DIN / ISO DIN 838
DIN / ISO ISO 1085
DIN / ISO ISO 3318
DIN / ISO ISO 10104
Surface Matt, chrom-plated
Length [mm] 248
Width [mm] 25
Height [mm] 11
Weight [kg] 0.17300
