Double-ring spanner 17 x 19 mm


Item no.: 01311SB
EAN: 4033592001991


variant: L SB
L: Loose and SB: SB-packing

Information about the product

Description

produced according to DIN 837 / ISO 1085

  • straight version
  • the slim shape and narrow heads guarantee a minimum space requirement
  • with SW-Stahl PRO DRIVE profile
    • specific inset corrugated profile which prevents the bolt from slipping or stripping
    • the enlarged contact surface ensures a reliable torque transfer
    • the optimally distributed transfer of force generates higher torques of up to 20%
  • galvanic coating for preventing corrosion
  • made from high-quality chrome vanadium steel
  • mat chrome-plated
  • packed on plastic hanger

Technical data

Specification PRO DRIVE
Material Chrome Vanadium Steel
Spanner Size 17
Spanner Size 19
Quality Premium
DIN / ISO DIN 837
DIN / ISO ISO 1085
Surface Matt, chrom-plated
Length [mm] 189
Width [mm] 28
Height [mm] 8
Weight [kg] 0.10100
